Description
FEATURES:
- Input Sensitivity Low Level: 120mVrms ~ 5.0 Vrms
- Parametric EQ with 0 – 12 dB Boost
- All Models Linkable with Single RCA for easy upgrade
- Short Circuit, Thermal, Reverse Voltage and Over Voltage Protection
- N-Channel Circuitry for High-Efficiency
- 24 dB Low Pass Crossovers with an adjustable range of 40Hz – 220Hz
- Heavy Duty Power Supply
- Illuminated Logo
- Heavy Duty Aluminum Heat Sink
- Designed and Engineered in U.S.A.
- Proprietary “Bass Kompressor” Circuitry provides Low-Frequency Enhancement
- Extreme Power in a Small Footprint
- “Q Control” to fine tune the curve on the bass boost
- “Clip Limit Switch” that will allow the amplifier to take up to 16.5 volts
- Adjustable Low Pass 18dB Sub Harmonic Filter with a range of 10Hz – 50Hz
- Adjustable center frequency range of 30-80 Hz
- Nickel Plated Connectors
- High Efficiency Class “D” Design
SPECIFICATIONS:
| RMS Power | 4000w x 1 |
| PEAK Power | 8000w x 1 |
| RMS @ 2 Ohms | 1500w x 1 |
| Bridged RMS | n/a |
| Min Impedance | 0.5 Ohm |
| Min Ohm Bridged | n/a |
| THD | <1% |
| S/N | 70dB* |
| Max Voltage | 12.5v – 16v |
| Max RCA Voltage | 5v |
| Freq. Response | 10Hz – 180Hz |
| Dimensions | 53 x 165 x 505 mm |
| Bass Remote | Optional (D Remote) |
