B2000.4 – 4 Channel Full Range Amplifier (Built-In OEM Line Converter)

The BLADE Series Amplifiers are designed with our “Price that Plays” motto. Blade amplifiers make CTA 2006 certified power and all but the B2000.1 are Class A/B full range. The built-in OEM line converters found in very model of BLADE use DC off set to activate the ATO (Auto Turn On). The RCA inputs can take high level speaker signal at up to 9 Volts in. BLADE even has a convenient 12V out feature to power up other products and a preparatory docking input for the custom built 4 Farad Rail Capacitor (RAILCAP-B). All multi-channel crossover adjustments can be programmed as high or low pass @ up to 3 KHz or Band Passed enabling the use with raw drivers. This ensures that no competition can stand up to the BLADE when it comes to features, performance and value.

Category:

Description

FEATURES:

  • Built-In OEM Line Converter
  • HPF, LPF, Band Pass Crossovers (12dB ~ 24dB)
  • Up to 9 Volt Input via RCA or High Level Speaker Leads
  • Bass Boost 0dB ~ 12dB @ 45Hz
  • Built-in Noise Reduction Circuitry
  • Full MOSFET with High Grade Switching Devices
  • Built-In, DC Offset, Auto Sensing Turn On Function (Hi-Level Inputs)
  • 12V Remote Output for External Devices (Hi-Level Inputs)
  • Variable Hi or Low Pass Crossover Frequencies from 50Hz ~ 3KHz
  • Ground Loop Isolator
  • Illuminated Soft Blue Logo back-lit with precisely placed LED’s
  • Next Generation Advanced 5 Way Protection Circuitry
  • RCB ~ 4 Farad Capacitor (Optional) (Except B2000.5)
  • CH 1/2 & CH 3/4 Crossover Select Switch
  • High Output Power Supply & Dual Output Voltage
  • Mil Spec PCB with SMD parts
  • World Wide Standards Compliant (RoHS, E-Mark, CTA-2006, CE)

SPECIFICATIONS:

Peak Output Power @ 14.4V 500W x 4
1 Ohm RMS n/a
2 Ohm RMS 300W x 4
4 Ohm RMS 150W x 4
4 Ohm Bridged 600W x 2
Input Level 0.2~9.0v
Freq. Response 10Hz~35KHz
THD at 4 Ohm Load 30% Rated Power <0.05%
S/N Ratio >90dB
BassBoost 0~12dB (45Hz)
Minimum Load 2 Ohm Stereo
Gain Remote n/a
Dimension
51 x 180 x 427 mm
